Now you can afford the ultimate inspection tool. Gain the competitive advantage and take care of more customers. Blow them away with dramatic MSX thermal images that clearly reveal problems from sources of energy loss, moisture intrusion and structural issues to overheating electrical and mechanical equipment.
FLIR EX Series of infrared cameras are easy to use, powerful and cost-effective troubleshooting tools for building, electrical and mechanical applications. A range of resolution options are available ranging from 80 x 60 IR pixels to 320 x 240. All cameras include MSX® technology that provides extraordinary thermal imaging detail. WiFi connectivity to smartphones and tablets via the FLIR Tools Mobile app makes sharing images and sending reports from any location easier. Enabling you to make critical decisions faster. By providing thermal images to help you find hidden problems along with accurate temperature measurements, an EX Series camera is the ideal tool.
FLIR E8 with Wi-Fi Comes Supplied With:
- FLIR E5 Thermal Camera
- Hard Transport Case
- USB Connectivity Cable
- Power Supply and Charger
- Rechargeable Battery
Key Features:
- Fully automatic and focus-free
- Simple button navigation to on-screen settings, imaging modes and measurement tools
- MSX adds digital camera detail to IR images for better perspective and interpretation
- 60 x 480 digital camera mode
- Rapid WiFi or USB image transfer for documentation
- Compact and rugged
- Suitable for use in harsh environments
- Lightweight (1.2 lb / 0.75 kg)
- Withstands 2 m drop test
- Accessory belt pouch included
- Field of View (FOV): 45° ´ 34°
- Minimum Focus Distance: 0.5 m
- Image Frequency: 9 Hz
- Focus: Focus free
- WiFi
- Detector Type: Uncooled microbolometer
- Display: 3.0" 320 x 240 colour LCD
- Image Modes: Thermal MSX®, thermal, picture-in-picture, thermal blending and digital camer
- Multi-Spectral Dynamic Imaging (MSX): IR image enhanced with visible camera detail
- Colour palettes Black and white, iron and rainbow
Flir E8 Specific Features:
-
IR Resolution: 320 ´ 240 pixels
- Thermal Sensitivity/NETD: <0.06°C (0.11°F) / <60 mK
- Image Adjustment: Automatic/Manual
A focus-free lens and simple button navigation to on-screen settings, imaging modes, measurement tools, and saved JPEGS make all four of these cameras amazingly easy to operate, even with just the press of a single gloved thumb.
Now you can afford the ultimate inspection tool. Gain the competitive advantage and take care of more customers. Blow them away with dramatic MSX thermal images that clearly reveal problems from sources of energy loss, moisture intrusion and structural issues to overheating electrical and mechanical equipment.
MSX adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one thermal picture with numbers, labels, and other structural features intact so you'll instantly recognize where the heat issue is.
Additional Features:
Rechargeable Batteries
Quick-release battery is easy to remove, change, and recharge
Measurement Accuracy
Min/max area box for auto hot/cold readings plus variable emissivity and reflected temperature settings for reliable results
Fast Download
Rapid image downloading via USB for sharing and documentation
Fast Temperatures
Area box with auto hot and cold spot hunts down extremes in no time
Quick Reports
FLIR Tools software to analyze images and create convincing reports
Warranty
2 years coverage on the camera, 5 on batteries, and 10 on the detector
Wi-Fi Connectivity:
No matter where you are, share images and send reports instantly from your smartphone or tablet via the FLIR Tools Mobile app, and make critical decisions faster!
